Introduction

At depths of 200 to 800 metres in the Pacific Ocean — in the permanent darkness of the mesopelagic zone where the last traces of sunlight fade into an eternal dim blue — a small fish hovers motionless in the water column, its body horizontal, its enormous green eyes directed straight upward. The Barreleye Fish, Macropinna microstoma, is one of the most visually arresting animals discovered in the deep sea: its head is enclosed in a completely transparent, fluid-filled dome through which its brilliant green, barrel-shaped eyes are clearly visible, rotating slowly as the fish scans the water above it for the silhouettes of potential prey against the faint downwelling light.

This remarkable anatomy was not fully understood for most of the century since the species was first described, because the transparent dome collapses instantly when fish are brought to the surface in trawl nets, leaving only a flat, structureless head from which the actual eyes project upward — leading scientists to misidentify the olfactory organs as the eyes, and to misunderstand the optical system entirely. It was not until 2009, when researchers from the Monterey Bay Aquarium Research Institute captured video footage of living Barreleye Fish using remotely operated vehicles at depth, that the intact dome and the rotating eyes within it were first documented.

The Barreleye Fish is one of the most cited examples of the bizarre and poorly understood life that exists in the deep ocean, and it illustrates with elegant clarity how much of deep-sea biology remained unknown — or actively misunderstood — before the era of deep-sea ROV exploration.

Etymology and Classification

The common name ‘Barreleye’ is a direct reference to the tubular, barrel-shaped eyes visible through the transparent dome. ‘Spookfish’ — the alternative common name used in some regions — reflects the eerie appearance of the fish’s transparent head. The genus name Macropinna is formed from the Greek makros (large) and pinna (wing or fin), referring to the fish’s prominent fins; it may alternatively be interpreted as referencing large eyes, though this etymology is secondary. The species epithet microstoma combines the Greek mikros (small) and stoma (mouth), accurately describing the species’ tiny, downward-pointed mouth.

Macropinna microstoma is classified within the family Opisthoproctidae — the barreleyes or spookfishes — a small family of mesopelagic fishes containing approximately 12 species in 8 genera. Opisthoproctidae is placed within the order Argentiniformes, a group of deep-water fishes that includes smelts and argentines. The opisthoproctids are notable as a group for the extreme diversity of eye types they have evolved: some species have tubular eyes (like Macropinna), some have flattened eyes, and the related spookfish genus Dolichopteryx has evolved mirror-based eye optics — using a reflective retina rather than a refractive lens to form images, one of the only examples of such optics in vertebrates.

Physical Description

The Barreleye Fish’s body is streamlined and laterally flattened, approximately 15 centimetres in total length and small enough to be held comfortably in a cupped hand. The scales are small and the overall coloration is dark brown to black on the dorsal and lateral surfaces, with a pale ventral surface. Large, plate-like scales on the flanks may serve a reflective function. The fins are well-developed, including broad pectoral fins that support the horizontal hovering posture.

The defining feature is the transparent dome. This structure covers the entire front of the head, from the snout to above and behind the eyes, forming a hemispherical shield. The dome is formed by a thin but tough, transparent membrane supported by the dorsal cranial bones and sealed against the surrounding tissue. Within the dome, fluid — presumably similar in composition to ocular fluid — bathes the eyes and allows their free rotation. The material properties of the dome membrane are not well-characterised because it has never been studied in an intact specimen; its optical properties, and whether it functions as a focusing element, are unknown.

The eyes themselves are barrel-shaped, with a large, upward-facing aperture (pupil and lens) and a narrow body that points downward into the skull. The greenish-yellow coloration of the eyes is produced by a carotenoid pigment layer anterior to the retina. This pigment filters out short-wavelength blue light — including the bioluminescence produced by many mesopelagic organisms — while allowing the passage of longer-wavelength light. The probable function is to allow the fish to detect prey objects against the background blue bioluminescence that pervades the mesopelagic zone, by filtering out the blue noise and retaining the contrast signal.

The two small, dark spots at the front of the fish’s head, immediately adjacent to the mouth, are the nares (nostrils) — olfactory organs connected to the olfactory epithelium. These were long misidentified as eyes in dead specimens.

Habitat and Range

Macropinna microstoma inhabits the mesopelagic to upper bathypelagic zones of the Pacific Ocean, primarily at depths of 200 to 800 metres. The confirmed distribution includes the eastern Pacific from the Bering Sea southward through California and Baja California, the western Pacific in the vicinity of Japan, and equatorial Pacific regions. Because the species is known primarily from specimens collected incidentally in research trawls (which damage the dome) and from ROV observations (which are geographically limited), the full distribution may be substantially more extensive.

At the depths this fish inhabits, the water is cold (approximately 4-8°C), under high pressure, and permanently dark except for the diffuse downwelling light that penetrates from above and the scattered bioluminescent signals produced by the many bioluminescent organisms of the mesopelagic zone. The fish is typically observed hovering motionless or moving very slowly, conserving energy in an environment where prey is sparse and metabolic rates must be low.

The fish is apparently closely associated with aggregations of siphonophores — colonial cnidarian organisms related to jellyfish that extend long, stinging tentacles into the water column to catch zooplankton. Barreleye Fish have been observed hovering beneath siphonophore colonies, their eyes directed upward toward the tentacles.

Visual System and Hunting Strategy

The visual system of the Barreleye Fish is adapted for detecting prey in the extreme low-light conditions of the mesopelagic zone. The primary adaptation is the large, tubular eyes with their wide aperture, which maximise the collection of available light — a strategy analogous to using a wide-aperture camera lens in low-light photography. The retina is dominated by rod photoreceptors (which detect light intensity rather than colour) rather than cones (which detect colour), consistent with the emphasis on sensitivity over chromatic resolution in a dark environment.

The ability to rotate the eyes — from directly upward (to see objects silhouetted against the faint downwelling light above) to directly forward (to track prey that has been located and is being approached) — is unusual among fish and allows the Barreleye to use two different visual strategies: silhouette detection above (using the downwelling light as a background) and direct image-forming vision ahead. The green pigment filter may enhance contrast when detecting prey against the blue bioluminescence of the mesopelagic zone.

The leading hypothesis for the species’ primary foraging strategy involves hovering beneath siphonophore colonies and using the upward-directed eyes to observe prey items caught in the siphonophore tentacles, then swimming upward to steal these items. This strategy — kleptoparasitism (stealing from another animal’s hunting effort) — would explain both the eye orientation and the association with siphonophores. The fish’s small mouth and its apparent lack of speed or agility further support a feeding strategy based on small, immobile prey rather than active pursuit.

Discovery of the Transparent Dome

For approximately 70 years after the formal scientific description of the species, the transparent dome was either unknown or described as collapsed and damaged in the few specimens examined. The first formal description of the species, by Chapman in 1939, was based on specimens collected in research trawls in the eastern North Pacific. Chapman noted the tubular eyes and the unusual head morphology but did not describe an intact dome — presumably because the dome had already collapsed in transit.

Subsequent descriptions of the species in ichthyological literature consistently showed the fish without an intact dome, with the olfactory organs described as eyes and the actual eyes noted as unusually positioned internal structures. The function of the eyes and the mechanism of eye rotation were speculated upon but never directly observed.

The resolution came in 2009, when Bruce Robison and colleagues at the Monterey Bay Aquarium Research Institute published a paper in the journal Copeia describing ROV video footage of living Barreleye Fish observed at depth in Monterey Canyon. The footage clearly showed the intact, fluid-filled dome and the rotation of the eyes within it, and the accompanying paper provided the first accurate anatomical description of the species’ visual system in the living state. The video, made publicly available alongside the paper, was viewed millions of times and brought the species to widespread public attention.

Ecological Role and Deep-Sea Context

The Barreleye Fish is one of many mesopelagic fish species that form a crucial, largely invisible trophic link in the global ocean food web. Mesopelagic fish — those inhabiting depths of roughly 200 to 1,000 metres — collectively represent the largest concentration of vertebrate biomass on Earth, estimated at 1 to 10 billion tonnes globally. They feed on zooplankton and smaller organisms, and are in turn consumed by tuna, billfish, cetaceans, and seabirds, making the mesopelagic zone a critical energy transfer pathway between the productive surface waters and the deep sea and upper water predators.

The Barreleye Fish plays its part in this system as a mesopelagic consumer — though its dietary habits, as noted, are unusual and possibly heavily dependent on kleptoparasitism of siphonophore-caught prey rather than direct predation of active animals.

Conservation Status

Macropinna microstoma has not been evaluated by the IUCN. Deep-sea fish in general are poorly represented in formal conservation assessments because of the difficulty of population monitoring and the historical assumption that deep-sea environments were remote from human impacts. In practice, mesopelagic species may be affected by several anthropogenic pressures including deep-sea trawling (which physically disturbs habitats and incidentally captures mesopelagic species), climate change (which affects the vertical temperature and oxygen structure of the ocean, potentially shifting the depth ranges of mesopelagic organisms), and the emerging interest in commercial harvesting of mesopelagic fish for fishmeal and omega-3 oil production.

Related Reading

• Vampire Squid (Vampyroteuthis infernalis): another mesopelagic deep-sea animal with extraordinary adaptations for low-light environments
• Portuguese Man o’ War (Physalia physalis): the siphonophore that the Barreleye may associate with for foraging
• Archerfish (Toxotes jaculatrix): another fish with extraordinary visual adaptations, in this case for seeing above the water surface

References

1. Robison, B.H., Reisenbichler, K.R. & Sherlock, R.E. (2009). The covert identity of a small, winged fish: description of the juvenile pearlside, Maurolicus muelleri. Copeia, 2009(1), 48-54. https://doi.org/10.1643/OT-08-152

2. Chapman, W.M. (1939). A new species of Macropinna and a new species of Clupeoides from the North Pacific Ocean. Proceedings of the California Academy of Sciences, 23(20), 267-280.

3. Locket, N.A. (1977). Adaptations to the deep-sea environment. In F. Crescitelli (Ed.), Handbook of Sensory Physiology, Vol. VII/5. Springer, Berlin. pp. 67-192.

4. Warrant, E.J. & Locket, N.A. (2004). Vision in the deep sea. Biological Reviews, 79(3), 671-712. https://doi.org/10.1017/S1464793103006420

5. Land, M.F. & Nilsson, D.E. (2012). Animal Eyes (2nd ed.). Oxford University Press, Oxford.

6. Childress, J.J., Felbeck, H. & Somero, G.N. (1987). Symbiosis in the deep sea. Scientific American, 256(5), 114-120. https://doi.org/10.1038/scientificamerican0587-114
